SMX Series

SMX1200RF Scraper

The Forced Ejection Series Scrapers offer positive control in unloading the entire soil load at the desired depth. Up to 20" of ground clearance allows the SMX Series to clear obstacles on the roughest work sites. Wide stance carrying wheels provide needed stability and easy access for maintenance. Narrow cutting widths provide easier and faster loading.

All RF Scrapers feature a two wheeled dolly which supports the front of the scraper and provides quick hook-up. All R Scrapers hitch directly to the tractor drawbar for maximum maneuverability. When equipped with a laser control package, these scrapers provide the best in finishing control. R models are available in 5 and 7-1/2 yd sizes.

SMX500RF offers large scraper features in a low horsepower, low price package. This, the smallest of the SMX series, has a cutting width of 7' and a capacity of 5 cu. yds. The SMX750RF has the same 7' cutting width but holds 7.5 cu. yds. For higher horse power tractors, the flagship SMX1200RF utilizes an 8' cutting width to fill its 12 cu. yd. capacity.

SMX750RF Scraper

Feedyard Scraper Series

SM312 Scraper

The Feedyard Scraper Series is designed for commercial applications not requiring actual transporting of material. These rugged scrapers are built for the high wear of everyday commercial use. Sidewall blades are replaceable for more mileage from your scraper. In addition, laser controls make these scrapers an excellent choice for finishing at large construction sites. The Feedyard Scraper Series is available in both a standard and a full featured "H.D." version.

The Feedyard scrapers can be tilted on either side to allow for shaping of the work area and to balance the loading of the scraper. The Feedyard scrapers provide a full 16 inch dumping height, and are excellent for leveling off building sites or maintaining roadways and waterways. The Feedyard scrapers are available in 12' and 14' cutting widths with 5.5 cu. yd. and 6.5 cu. yd. capacities.

The H.D. Feedyard Scrapers feature a massive "A" frame hitch, dual hydraulics and additional structural reinforcements.

As an option, H.D. Feedyard scrapers can be ordered with a tilt feature and swivel hitch, allowing the operator complete control in shaping and loading. With a maximum dumping height of 32", the H.D. Feedyard scraper will move and unload a mountain of dirt quickly. Built to harness the power of 150-275 hp tractors, the H.D. Feedyard scraper is available in 10', 12', 14' and 16' cutting widths, with 5 cu. yd., 7 cu. yd., 9 cu. yd., and 11 cu. yd. capacities respectively.

SM212 Scraper

 GP Series

GP1025 Scraper

The General Purpose Scraper Series is
the perfect match to perform earthmoving tasks with a low to medium horsepower tractor. The GP Series is versatile and rugged enough to be used around landscape projects, farmsteads, ranches or just down the lane, wherever it might be needed. The 10' and 12' models feature an adjustable tilt axle to allow for shaping of the work area and complete loading control. The GP series is available in 10' and 12' cutting widths for use with 100 - 150 hp tractors, with capacities of 2.5 cu. yd. and 3 cu. yd.


DYSS Scraper Specifications

Model
Capacity
(heaped)
Width
of Cut
Weight
Overall
Width
Overall
Length
Overall
Height
Recommended
Horsepower
Tire Size
Front
Tire Size
Rear
Forced Ejection Finishing Scrapers
SMX1200RF
12 cu. Yd.
8'
9,650
9' - 9"
24' - 9"
84"
185-250
16.5L x 16.1 10 ply
21.5L x 16.1 10 ply
SMX750RF
7.5 cu. Yd.
7'
6,700
8'
20'
60"
100-150
16.5L x 16.1 10 ply
16.5L x 16.1 10 ply
SMX750R
7.5 cu. Yd.
7'
7,100
8'
20'
60"
100-150
N/A
16.5L x 16.1 10 ply
SMX500RF
5 cu. Yd.
7'
4,700
8'
19' - 3"
53"
75-125
11L x 15 8 ply
11L x 15 8 ply
SMX500R
5 cu. Yd.
7'
5,000
8'
19' - 3"
53"
75-125
N/A
11L x 15 8 ply
Clam Discharge Carry-All Scrapers
SM50RF
5.5 cu. Yd.
6' - 6"
3,640
8'
18' - 6"
48"
60-120
9.5L x 15 6 ply
11L x 15 8 ply
SM50R
5.5 cu. Yd.
6' - 6"
3,450
8'
16'
48"
60-120
N/A
11L x 15 8 ply
SM35RF
3 cu. Yd.
6'
2,310
7' - 3"
16' -5"
38"
40-80
9.5L x 15 6 ply
9.5L x 15 6 ply
SM35R
3 cu. Yd.
6'
2,070
7' - 3"
14' -9"
38"
40-80
N/A
9.5L x 15 6 ply
H.D. FEEDYARD Scrapers
SM316
11 cu. Yd.
16'
4,700
16' - 4"
18'
80"
200-275
N/A
16.5L x 16.1 10 ply
SM314
9 cu. Yd.
14'
4,450
14' - 4"
15' - 6"
80"
200-275
N/A
16.5L x 16.1 10 ply
SM312
7 cu. Yd.
12'
4,200
12' - 4"
15' - 6"
80"
175-250
N/A
16.5L x 16.1 10 ply
SM310
5 cu. Yd.
10'
3,800
10' - 4"
15' - 6"
80"
150-225
N/A
16.5L x 16.1 10 ply
FEEDYARD Scrapers
SM214
6.5 cu. Yd.
14'
3,400
14' - 1"
13' - 6"
55"
175-225
N/A
11L x 16 Tri 8 ply
SM212
5.5 cu. Yd.
12'
3,100
12' - 1"
13' - 6"
55"
155-200
N/A
11L x 16 Tri 8 ply
Planing Scrapers
SM112
3.0 cu. Yd.
12'
1,660
12' - 1"
11' - 8"
39"
40-80
N/A
9.5L x 15 6 ply
SM110
2.5 cu. Yd.
10'
1,450
10' - 1"
11' - 8"
39"
30-60
N/A
9.5L x 15 6 ply
SM108
2 cu. Yd .
8'
1,240
8' - 1"
11' - 8"
39"
20-40
N/A
9.5L x 15 6 ply
General Purpose Scrapers
GP1230
3 cu. Yd.
12'
1,910
12' - 1"
12' - 6"
44"
125-150
N/A
11L x 15 8 ply
GP1025
2.5 cu. Yd .
10'
1,800
10' - 1"
12' - 6"
44"
100-125
N/A
11L x 15 8 ply
